Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
| Processor | Intel® 2.6GHz Dual-core Processor
|
|---|---|
| Memory | DRAM:
2GB SO-DIMM RAM
Flash Memory: 512MB DOM
|
| Chassis | Tower
|
| Dimensions | 175mm(H)x 257mm(W)x 235mm(D)
6.89"(H)x 10.12"(W)x 9.25"(D) |
| Drive Bays | 6x Hot-swappable tray with key lock
3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD NOTE: The system is shipped without HDD. |
| Expansion Slots | PCI-E Slot
1x with dual-port GbE NIC pre-installed (for optional 10GbE network expansion) |
| Power Supply | Input: 100-240V AC, 50/60Hz
Output: 250W |
| Front Panel | Buttons
Power, Reset, USB One Touch Backup LED Indicators Status, USB, LAN, HDD 1 - 6 LCD Panel
Mono-LCD display with backlight, Enter and Select buttons for configuration |
| Input / Output | LAN Port
4x Gigabit RJ-45 Ethernet port (2 ports are provided by the included PCI-E NIC); Optional dual-port 10 GbE NIC support by replacing the dual-port GbE PCI-E NIC USB
2 x USB 3.0 port (rear) 3 x USB 2.0 port (front: 1, rear:2) Support USB printer, pen drive, USB hub (front), and USB UPS etc. eSATA
2 x eSATA port (rear) HDMI
HDMI x 1 IR Built-in Infrared Receiver (IR) for MCE remote control Audio Out 1 (Supported application: Music Station, HD Station) Audio In 1 (reserved) |
| Cooling | 2x quiet cooling fan (9 cm, 12V DC)
|
| Detailed Specification | Alarm Buzzer
System warning Power Consumption (W) Sleep mode: 26.3W In Operation: 49.8W Power-off (in WOL mode): 1W (with 6 x 500GB HDD installed) Temperature 0-40˚C Humidity 5~95% RH non-condensing, wet bulb: 27˚C |
