Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
| Processor | 2 x Socket P (LGA 3647) (CPU not included)
1st and 2nd Gen Xeon® Scalable Processor Family (150W) Intel® Lewisburg PCH C621
|
|---|---|
| Memory | Total Slots:
16 (6-channel per CPU, 8 DIMM per CPU) (Memory not included) Capacity:
Maximum up to 2048GB LRDIMM Memory Type:
DDR4 2933/2666/2400 /2133 RDIMM DDR4 2933/2666/2400 /2133 LRDIMM DDR4 2933/2666/2400 /2133 LR-DIMM 3DS DDR4 Intel® Optane™ DC Persistent Memory Memory Size:
64GB, 32GB, 16GB RDIMM 128GB, 64GB, 32GB LRDIMM 128GB, 64GB LR-DIMM 3DS |
| Chassis | 2U Rackmount Chassis
|
| Dimensions | 800mmx 440mmx 88mm
|
| Drive Bays | 8x Hot-swap 3.5" HDD Bays (HDD not included)
SATA Controller :
Intel® C621 8x SATA3 6Gb/s ports + 1 x M.2 connector (SATA 6Gb/s & PCI-E Gen3 x4 link /2280/2260) or 6x SATA3 6Gb/s ports + 2 x U.2 NVMe drives + 1x M.2 connector (SATA 6Gb/s & PCI-E Gen3 x4 link /2280/2260) Intel® Rapid Storage Technology Enterprise(RSTe) (For Linux/Windows) (Support Software RAID 0, 1, 5, 10 ) SAS Controller :
ASUS PIKE II 3008 8-port SAS HBA card ASUS PIKE II 3108 8-port SAS HW RAID card 12G SAS Support (SAS adapters not included) |
| Expansion Slots | Total: 8 + 3
Full-length/Full-height 8x PCI-E 3.0 x16 (4 at x16 Link or 8 at x8 Link) Half-length/Low-profile
Rear:
1x PCI-E 3.0 x24 (support with riser card) (1x PCI-E x16 (x16 Gen3 Link) and 1x PCI-E x8 (x8 Gen3 Link)) Front:
1x PCI-E x8 (internal HBA/RAID card) |
| Power Supply | 1+1 Redundant 2200W 80 PLUS Platinum Power Supply
200-240Vac,9.5A, 2200W |
| Onboard Devices | Networking:
1x Dual Port Intel I350-AM2 Gigabit LAN controller + 1x Mgmt LAN Graphic:
Aspeed AST2500 with 64MB VRAM |
| Input / Output | Front I/O Ports:
1x 80 port 2x USB 3.0 ports + 2 x USB 2.0 ports Rear I/O Ports:
2x USB 3.0 port 1x VGA port 1x RJ-45 Mgmt LAN port 2x RJ-45 GbE LAN ports Switch/LED:
Rear Switch/LED: 1x Power switch/LED 1x Location LED 1x Message LED 1x HDD Access LED Front Switch/LED:
1x Power switch/LED 1x Location switch/LED |
| Operating Environment | Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃
Non operation humidity: 20% ~ 90% ( Non condensing) |
| Detailed Specification | Management Solution
ACC On-Board ASMB9-iKVM for KVM-over-IP Condition:
Seller refurbished |
