Note: Image above may show a varied configuration or optional part. Please refer to parts list for standard parts included.
| Processor | Dual Core Intel® Core™ i3-3220 Processor 3.3 GHz
|
|---|---|
| Memory | Memory:
System memory: 4 GB DDR3 RAM Memory module pre-installed: 4 GB x1 Total memory slots: 4 Memory expandable up to: 32 GB (8GB x4) Note: When upgrading RAM to more than 28GB, the original 4GB RAM modules must be removed. Flash Memory: 512MB DOM |
| Chassis | 2U Rackmount
|
| Dimensions | 3.46"(H) x 17.28"(W) x 20.47"(D)
|
| Drive Bays | 12x 3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
Hard Drive Tray: 12x hot-swappable and lockable tray |
| Expansion Slots | 2x Expansion Slot
(for network and storage expansion) |
| Power Supply | Input: 100-240V AC,50-60Hz
Output: 600W |
| Front Panel | Button:
Power Button
LED Indicators:
Status, 10 GbE, LAN, eSATA, hard drives |
| Input / Output | LAN Port:
2x Gigabit RJ-45 Ethernet port (Optional dual-port 10 Gb and 1 Gb network card are supported) USB: 2x USB 3.0 port (rear) 4x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc.
eSATA:
2 (rear) |
| Cooling | 3x 6 cm smart cooling fan
|
| Detailed Specification | Sound Level (dB):
Standby: 48.17 dB In operation:48.17 dB (with12 x 1TB HDD installed) Power Consumption (W): Sleep mode: 68 W In Operation: 165 W (with 12 x 1TB hard drive installed) Temperature: 0~40˚C Relative Humidity: 5~95% RH non-condensing, wet bulb: 27˚C. |
